INTRODUCING THE Type 980…
Direct Spring Loaded Enclosed Discharge safety valve for Liquids – Metal seal.
Available with 10, 15, 20 & 25mm bore
Materials:
Stainless steel with AISI 440B Disc
Notes:
- Relieving pressure is set pressure +10%
- Reseating pressure is set pressure -20% (0.6 bar below 3.0 bar)
- Leak Tightness to 90% set pressure to API 527 and in accordance with EN ISO 4126-1.
Approvals:
- Designed in accordance with BS EN ISO-4126-1 & -7
- PED 2014/68/EU (CE)
- PE(S)R UK SI 2016 No. 1105 (UKCA)
- Leak tightness at 90% set pressure to API 527 and in accordance with EN ISO 4126-1
Example Applications:
- Pumping systems and Hydraulic systems
- Thermal relief
- Waste water management
- Oil transfer
- Petrochemical industries
- Fire fighting equipment
- Water cooling and feeding systems
- Chemical process
